YH4
GRAND
VITARA
6A4-8 ENGINE MECHANICAL (J20 ENGINE)
AIR CLEANER ELEMENT
REMOVAL
1) Remove air cleaner case clamps.
2) Remove air cleaner element from case.
INSPECT
Check air cleaner element for dirt. Replace excessively dirty ele-
ment.
CLEAN
Blow off dust by compressed air from air outlet side of element.
INSTALLATION
Reverse removal procedure for installation.
