CRANKING SYSTEM 6G-17
SPECIFICATIONS
1.2 kW type (1.4 kW type)
Voltage 12 volts
Output 1.2 kW (1.4 kW)
Rating 30 seconds
Direction of rotation Clockwise as viewed from pinion side
Brush length 12.3 mm (0.44 in.) (16.5 mm (0.65 in.))
Number of pinion teeth 8
Performance Condition Guarantee
No load characteristic 11.0 V
90 A maximum
2,500 rpm minimum (3,000 rpm minimum)
Around
at 20 _C
Load characteristic
7.5 V
(7.7 V)
300 A
10.5 N
.
m (1.05 kg-m, 7.59 lb-ft) minimum
880 rpm minimum
9.81 N
.
m (0.98 kg-m, 7.0 lb-ft) minimum
1,000 rpm minimum
a
t
20
_C
(68 _F)
Locked characteristic 4.0 V
760 A maximum
19.5 N
.
m (1.95 kg-m, 14.1 lb-ft) minimum
980 A maximum
23 N
.
m (2.3 kg-m, 16.5 lb-ft) minimum
Magnetic switch operating
voltage
8 volts maximum
0.9 kW type
Voltage 12 volts
Output 0.9 kW
Rating 30 seconds
Direction of rotation Clockwise as viewed from pinion side
Brush length 12.3 mm (0.44 in.)
Number of pinion teeth 8
Performance Condition Guarantee
No load characteristic 11.0 V
90 A maximum
2,800 rpm minimum
Around
at 20
_
C
Load characteristic
8 V
200 A
4.8 N
.
m (0.48 kg-m, 3.5 lb-ft) minimum
1,260 rpm minimum
at
20
_C
(68 _F)
Locked characteristic 3.5 V
550 A maximum
12.2 N
.
m (1.22 kg-m, 8.9 lb-ft) minimum
Magnetic switch operating
voltage
8 volts maximum
