DF2.5 (Serial No. 410001 and later) 5
CYLINDER HEAD/CAMSHAFT
Item Unit
Data
DF2.5
Cylinder head
distortion
Limit mm (in) 0.05 (0.002)
Cam
height
IN,
EX
STD mm (in) 28.480 – 28.680 (1.1213 – 1.1291)
Limit mm (in) 28.180 (1.1094)
Rocker
arm shaft
hole
diameter
IN
STD mm (in) 4.015 – 4.027 (0.1581 – 0.1585)
EX
Rocker
arm shaft
outside
diameter
IN
STD mm (in) 3.990 – 4.005 (0.1571 – 0.1577)
EX
