14 DF2.5 (Serial No. 410001 and later)
3. Install the gasket 2 and the thermostat cover 3 to the cylin-
der block and secure with the two bolts 4.
4. Install the two nuts 6 to the fuel pump bracket 5.
5. Install the fuel pump bracket 5 to the thermostat cover 3
and secure with the two bolts 7.
6. Install the fuel pump 8 to the fuel pump bracket 5.
7. Apply the Thread Lock to fuel pump mounting bolts.
J 99000-32050: THREAD LOCK “1342”
8. Tighten fuel pump mounting bolts 9 to specified torque.
" Fuel pump mounting bolt: 6 N·m (0.6 kg-m, 4.5 lb-ft)
To Next Page
