18 DF2.5 (Serial No. 410001 and later)
REMOVAL
1. Remove the motor cover.
2. Remove the recoil starter assembly 1. (See the DF2.5 Ser-
vice Manual, page 5-2.)
3. Turn the fuel cock lever 2 “OFF” position and tighten the air
vent screw on the fuel filler cap.
4. Remove the fuel hose 3 from the fuel cock 4 and immedi-
ately plug the fuel hose 3 in order to avoid fuel flow from the
hose.
#
5. Remove the fuel tank 5.
Wipe up fuel spills immediately.
To Next Page
