Suzuki DF225 User Manual

56
SPECIFICATIONS
Power rated in accordance with NMMA procedure.
CHART OF TOTAL OPERATING HOURS INDICATION
*: One flashing is corresponded to 500 hours.
Item DF200 DF225 DF250
Engine Type 4 Stroke
Number of Cylinders 6
Bore and Stroke 95.0 × 85.0 mm
(3.74 × 3.35 in.)
Piston Displacement 3614 cm
3
(220.5 cu. in.)
Maximum output 147.1 kW (200PS) 165.5 kW (225PS) 183.9 kW (250PS)
Full Throttle Operating Range 5000 – 6000
r/min. (min
–1
)
5500 – 6100
r/min. (min
–1
)
Idle speed (in Neutral) 650 ± 50 r/min. (min
–1
)
Ignition System Full-transistor
Engine Lubrication Trochoid pump pressure lubrication
Engine Oil Capacity 8.0 L (8.5/7.0 US/Imp. qt.)
Tot al
operating
hours
MONITOR-TACHOMETER
Needle 1
indication
REV-LIMIT
lamp 2 flashing *
0h-(49h) No No
50h- 500rpm
No
60h- 600rpm No
:
:
:
:
:
:
540h- 5400rpm No
550h- 500rpm 1 time
560h- 600rpm 1 time
:
:
:
:
:
:
1040h- 5400rpm 1 time
1050h- 500rpm 2 times
:
:
:
:
:
:
1540h- 5400rpm 2 times
1550h- 500rpm 3 times
:
:
:
:
:
:
2030h- 5300rpm 3 times
2040h or over 5400rpm 3 times
