78
LOW PRESSURE FUEL FILTER
The low pressure fuel filter must be replaced by
an authorized Suzuki Marine Dealer periodi-
cally.
Replace low pressure fuel filter at every 400
hours (2 years).
Inspect and clean the fuel filter as follows:
1. Turn the engine off and allow it to cool.
2. If equipped with Keyless Start System:
Make sure that the keyless start system is in
OFF stage.
If not equipped with Keyless Start System:
Make sure that the ignition key is in the OFF
position.
8
WARNING
Gasoline is extremely flammable and toxic. It
can cause a fire and can be hazardous to peo-
ple and pets.
Always take the following precautions when
servicing the fuel filter:
• Stop the motor before cleaning the fuel fil-
ter.
• Be careful not to spill fuel. If you do, wipe it
up immediately.
• Do not smoke, and keep away from open
flames and sparks.
8
WARNING
Cleaning solvent is toxic and an irritant, and
can cause injury to people and pets.
Keep solvent away from children and pets.
Dispose of solvent properly when you are fin-
ished.
3. Remove the bolts 1 securing the fuel filter
cap 2 in place.
4. Push the connector lock tab “a”, then discon-
nect the water sensor lead wire connector
3.
NOTICE
Improperly loosening the filter cup can cause
sensor lead wire damage.
• Be careful not to twist the sensor lead wire
when removing the filter cup.
• Disconnect the lead wire connector before
removing the filter cup.
To Next Page
