Suzuki DF8A - Page 59

DF8AE/DF9.9AE (ELECTRIC STARTER MODEL)
M
RECTIFIER & REGULATOR
PULSER COIL
CDI UNIT
STARTER MOTOR
FUSE 20A
STARTER MOTOR RELAY
B
P
B
Br
Y/G
Br
Y/G
B
Bl/R
B
Bl/R
W/R
Br
W/R
Br
P
B
OO
B
Y Y Y Y Y Y R R
W/R
R
R R
R
R
W W
B
B
B
B
B
Y/G
CAUTION LAMP
(OIL PRESSURE)
MAGNETO
Bl
IGNITION COIL
SPARK PLUG
BATTERY
B
R
B
R/B
G
B/R
Bl/R
Bl
O
P
Lg/W
Y/B
B
Lg/W
B
B
B
NEUTRAL SWITCH
N ON
F. R OFF
START SWITCH PUSH START
EMERGENCY STOP & ENGINE STOP SWITCH Emergency stop switch: Lock plate IN RUN Lock plate OUT STOP Engine stop switch: Button pushed STOP
CYLINDER TEMP SENSOR
OIL PRESSURE SWITCH
CONDENSER CHARGE COIL
BATTERY CHARGE COIL
WIRE COLOR B.......... Black Bl......... Blue Br......... Brown G.......... Green O.......... Orange
P........... Pink R.......... Red W......... White Y........... Yellow B/R....... Black/Red
BI/R...... Blue/Red R/B....... Red/Black W/R...... White/Red Y/B....... Yellow/Black Y/G...... Yellow/Green Lg/W.... Light green/White
PTC HEATER
HI
LO
