ENGINE 3-5
• Remove the two wire clamps.
• Disconnect the starter motor lead wire 1.
• Disconnect the generator lead wire 2 and coupler 3.
• Remove the gearshift lever by removing its mounting bolt.
• Remove the engine sprocket cover by removing the bolts.
"
Do not operate the clutch lever to prevent clutch piston
retainer damage.
• Loosen the rear axle nut 5 and chain adjusters 6 to provide
additional chain slack.
• Flatten the lock washer.
• Remove the engine sprocket nut while depressing the rear brake
pedal.
# Engine sprocket nut: 115 N
.
m (11.5 kgf-m)
• Remove the engine sprocket.

Suzuki GSX1200 1999 Specifications

General

Displacement	1157 cc
Bore x Stroke	79.0 mm x 59.0 mm
Compression Ratio	9.5:1
Ignition	Electronic ignition (Transistorized)
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Starting	Electric
Engine Type	4-stroke, 4-cylinder, DOHC
Fuel System	Mikuni BSR36SS carburetors
Transmission	5-speed
Rear Suspension	Link-type, coil spring, oil damped
Ground Clearance	135 mm
Seat Height	790 mm
