FI SYSTEM DIAGNOSIS 4-27
MALFUNCTION CODE AND DEFECTIVE CONDITION
DTC No.
DETECTED
ITEM
DETECTED FAILURE CONDITION CHECK FOR
C00 NO FAULT
––––––––––– –––––––––––
C12
CKP sensor The signal does not reach ECM for 3
sec. or more, after receiving the starter
signal.
CKP sensor wiring and mechan-
ical parts
CKP sensor, lead wire/coupler
connection
P0335
C13/C17
IAP sensor The sensor should produce following
voltage.
0.5 V sensor voltage < 4.85 V
In other than the above range, C13
(P1750) (#2 cylinder) or C17 (P0105)
(#1 cylinder) is indicated.
IAP sensor, lead wire/coupler
connection
P1750/
P0105
H
Sensor voltage is higher than specified
value.
IAP sensor signal circuit shorted
to VCC or ground circuit open
L
Sensor voltage is lower than specified
value.
IAP sensor signal circuit open or
shorted to ground or VCC circuit
open
C14
TP sensor The sensor should produce following
voltage.
0.2 V sensor voltage < 4.8 V
In other than the above range, C14
(P0120) is indicated.
TP sensor, lead wire/coupler
connection
P0120
H
Sensor voltage is higher than specified
value.
TP sensor signal circuit shorted
to VCC or ground circuit open
L
Sensor voltage is lower than specified
value.
TP sensor signal circuit open or
shorted to ground or VCC circuit
open
C15
ECT sensor The sensor voltage should be the fol-
lowing.
0.15 V sensor voltage < 4.85 V
In other than the above range, C15
(P0115) is indicated.
ECT sensor, lead wire/coupler
connection
P0115
H
Sensor voltage is higher than specified
value.
ECT sensor circuit open or
ground circuit open
L
Sensor voltage is lower than specified
value.
ECT sensor circuit shorted to
ground
C21
IAT sensor The sensor voltage should be the fol-
lowing.
0.15 V sensor voltage < 4.85 V
In other than the above range, C21
(P0110) is indicated.
IAT sensor, lead wire/coupler
connection
P0110
H
Sensor voltage is higher than specified
value.
IAT sensor signal circuit open or
ground circuit open
L
Sensor voltage is lower than specified
value.
IAT sensor signal circuit shorted
to ground
