Suzuki GW250 User Manual

8-18 CHASSIS
• Remove the dust seal F and oil seal stopper ring G.
• Pull the inner tube out of the outer tube.
• Remove the oil lock piece H.
• Remove the following parts from the inner tube.
I Outer tube slide bushing
J Spacer
K Oil seal
INSPECTION
INNER AND OUTER TUBES
Inspect the inner tube sliding surface and outer tube sliding sur-
face for any scuffing and damage. If any defects are found,
replace them with new ones.
FORK SPRING
Measure the fork spring free length. If it is shorter than the ser-
vice limit, replace it with a new one.
 Front fork spring free length:
Service Limit: 270 mm (10.6 in)
Be careful not to damage the inner tube.

Suzuki GW250 Specifications

General

Engine Type	4-stroke, 2-cylinder, liquid-cooled, SOHC
Displacement	248 cc
Bore x Stroke	53.5 mm x 55.2 mm
Compression Ratio	11.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (Transistorized)
Starter	Electric
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm type, coil spring, oil damped
Front Tire	110/80-17M/C 57H, tubeless
Rear Tire	140/70-17M/C 66H, tubeless
Curb Mass	183 kg (403 lbs)
Front Brakes	Single disc
Rear Brakes	Single disc
Fuel Tank Capacity	13.3 liters
Overall Width	760 mm
Overall Height	1, 075 mm
Wheelbase	1, 430 mm
Ground Clearance	165 mm (6.5 in)
Seat Height	780 mm (30.7 in)
Overall Length	2, 145mm (84.4 inches)
