4A-13
Brake Control System and Diagnosis:
Rear Brake Pedal Constru
ction
B831G24106017
“a”
1
2
3
(a)
4
I831G1410038-04
1.
Brake pedal
4.
Brake pedal pivot bolt
:
Apply water resistance grease.
2.
Brake light switch
“a”:
17.5 mm (0.69 in)
:
Apply thread lock to the thread part.
3.
O-ring
:
1
1 N
⋅
m (1
.1 kgf-m, 8.
0 lb-ft)
:
D
o not reuse.
