2-107
BEFORE DRIVING
80SS5-01E
Energy flow
The state of SHVS operation can be checked on the information display. For details, refer
to “SHVS (Smart Hybrid Vehicle by Suzuki) (for K14D engine model)” or “SHVS (Smart
Hybrid Vehicle by Suzuki) (for K12C engine model and K12D engine model)” in “OPER-
ATING YOUR VEHICLE” section.
Information display Description
52RM20780
When the vehicle is running, ISG (Integrated Starter Generator)
assists engine power as an electric motor.
52RM20790
When the vehicle is powered by the engine.
52RM20770
When decelerating your vehicle, the ISG generates electricity
without engine power.
52RM20800
When the engine automatically stops by the ENG A-STOP sys-
tem.
Vehicle speed
Vehicle speed is shown.
You can change the unit of velocity that
vehicle speed is displayed in. Refer to
“Setting mode” in this section.
NOTE:
Displayed vehicle speed may differ a little
from the speed meter indication.
