7-66
INSPECTION AND MAINTENANCE
80SS5-01E
Fuses in engine compartment
52RM70310
(1) Main fuse box
(2) Relay box
(3) Sub relay box
Main fuse box
74LHT0715
Relay box
52RM210
Sub relay box
(for K10C, K12C, K12D, K12M and K14C
engine model)
52RM211
(for K14D engine model)
80SM016
(for K10C, K12C, K12M and K14C
engine model)
(1)
(2)
(3)
(5)
(3)
(4)
(2)
(1)
(5)
(4)
(3)
(2)
(1)
(6)
EXAMPLE
without SHVS with SHVS
(7)
(12)
(13)
(14)
(15)
(16)
(17)
(18)
(19)
(20)
(21)
(22)
(24)
(25)
(26)
(27)
(28)
(29)
(30)
(23)
(8)
(9)
(10)
(11)
(31)
(35)
(36)
(37)
(32) (33) (34)
MAIN FUSE / PRIMARY FUSE
(1)
120 A
FL1
(2)
100 A
FL2
(3)
80 A
FL3
(4)
100 A
FL4
(5)
50 A
FL5
(6)
150 A
FL6
*6
(7)
30 A
Starting motor
(8)
30 A
Blower fan
(9)
40 A
Battery
*1
(10)
40 A
ABS motor
(11)
40 A
Ignition switch
(44)
(45)
(46)
(47)
(48)
(43) (42)
To Next Page
