7-67
INSPECTION AND MAINTENANCE
80SS5-01E
*1: Models with Auto-on headlight system
or LED headlights
*2: K12C and K12M engine models
*3: K10C engine models
*4: Models with automatic transmission or
CVT
*5: Sport models
*6: K12C engine model with SHVS
(for K12D and K14D engine models)
(12)
30 A
B/U
(13)
30 A
SUB BAT
*6
(14) – Blank
(15) – Blank
(16)
25 A
ABS control module
(17)
15 A
Headlight (Left)
(18)
15 A
Headlight (Right)
(19) – Blank
(20)
40 A
Radiator fan
*3, *5
30 A
Radiator fan
*2
(21)
30 A
Radiator fan 2
*5
(22)
60 A
Power steering
(23) – Blank
(24) – Blank
(25)
20 A
Front fog light
(26)
10 A
Air compressor
(27)
50 A
Ignition switch 2
(28)
15 A
Transmission
*4
(29)
15 A
FI
*2
30 A
FI main
*3, *5
(30)
20 A
Fuel Pump
*3, *5
(31) – Blank
(32) – Blank
(33)
5 A
Starting Signal
(34) – Blank
(35)
20 A
INJ DRV
*3, *5
(36) – Blank
(37)
10 A
FI
*3, *5
(38) – Blank
(39)
25 A
Headlight high
*1
(40)
15 A
Headlight high (Right)
*1
(41)
15 A
Headlight high (Left)
*1
MAIN FUSE / PRIMARY FUSE
(1)
120 A
FL1
(2)
100 A
FL2
(3)
80 A
FL3
(4)
100 A
FL4
(5)
50 A
FL5
(6)
150 A
FL6
*1
175 A
FL6
*2
(7)
30 A
Starting motor
(8)
30 A
Blower fan
*2
(9)
40 A
Battery
*3
(10)
40 A
ABS motor
(11)
40 A
Ignition switch
(12)
30 A
B/U
(13)
10 A
Sub battery
*2
To Next Page
