INSPECTION AND MAINTENANCE
80SS5-01E
*1: K12D engine models
*2: K14D engine models
*3: Models with Auto-on headlight system
or LED headlights
(for K12D engine models)
*4: Models with air conditioning system
(for K14D engine models)
*5: Models with CVT and SHVS (for K12D
engine models)
The main fuse, primary fuses and some of
the individual fuses are located in the
engine compartment. If the main fuse
blows, no electrical component will func-
tion. If a primary fuse blows, no electrical
component in the corresponding load
group will function. When replacing the
main fuse, a primary fuse or an individual
fuse, use a genuine SUZUKI replacement
parts or equivalent for individual fuses.
To remove a fuse, use the fuse puller pro-
vided in the fuse box. The amperage of
each fuse is shown in the back of the fuse
box cover.
(14) – Blank
(15) – Blank
(16)
25 A
ABS control module
(17)
15 A
Headlight (Left)
*1
(18)
15 A
Headlight (Right)
*1
(19) – Blank
(20)
40 A Radiator fan
*1
40 A FI MAIN
*2
(21) – Blank
(22)
60 A
Power steering
(23) – Blank
(24) – Blank
(25)
20 A
Front fog light
(26)
10 A
Air compressor
*4
(27)
50 A
Ignition switch 2
(28)
20 A
VVT
(29)
15 A
FI
*1
(30)
15 A
T/M
*1
20 A
Fuel Pump
*2
(31) – Blank
(32) 15 A T/M Pump
*5
(33)
5 A
Starting Signal
(34) 10 A Air compressor
*1
(35)
20 A
INJ DRV
*2
(36) 15 A FL2
*2
(37)
10 A
FI
*2
(38) – Blank
(39)
25 A
Headlight high
*3
(40)
15 A
Headlight high (Right)
*3
(41)
15 A
Headlight high (Left)
*3
(42)
15 A
Headlight high (Left)
(43)
15 A
Headlight high (Right)
(44)
30 A
RDTR
(45)
40 A
RDTR
(46)
15 A
Headlight (Right)
(47)
15 A
Headlight (Left)
(48)
25 A
Headlight high
To Next Page
