7-74
INSPECTION AND MAINTENANCE
80SS5-01E
68PM00721
(3) Removal
(4) Installation
2) To remove the bulb of the front turn sig-
nal light (1) from the bulb holder, push
in the bulb and turn it counterclockwise.
To install a new bulb, push it in and turn
it clockwise.
To remove and install the bulb of the
front position light (2), simply pull out or
push in the bulb.
Side turn signal light
Outside rearview mirror type
LED is used. It is recommended that you
take your vehicle to an authorized SUZUKI
dealer for light replacement since special
procedures are required.
Fender type
64J195
Since the bulb is built-in type, replace it as
the light assembly. Remove the light
assembly by sliding the light housing left-
ward with your finger.
Front fog light (if equipped)
1) Start the engine. Turn the steering
wheel to the opposite side of the fog
light to be replaced to replace the bulb
easily. Then turn off the engine.
52RM70150
2) Remove the clip (1) and screws (2) at
the bottom of bumper.
For removing the clip, use a flat blade
screwdriver as show in the illustration.
To Next Page
