5-124
OPERATING YOUR VEHICLE
69TB-01E
When the driver operates turn signal con-
trol lever to the detected side, an interior
buzzer sounds and the indicator on the
outside rearview mirror blinks.
69T050780
Detecting area
Vehicle entering the following areas can be detected.
69T050770
(a) An area about 0.5 to 4.0 m (1.6 to 13.1 ft) from both sides of the vehicle
(b) An area between the rear bumper and near the driver’s seat
(c) An area about 4.0 m (13.1 ft) behind the rear bumper
(d) An area between about 4 and 50 m (13.1 and 164 ft) behind the rear bumper
NOTE:
The greater the difference in speed between your vehicle and the detected vehicle is, the
farther away the vehicle will be detected, causing the outside rearview mirror indicator to
illuminate or blink.
(1)
(2)
(b)
(a)
(c)(d)
To Next Page
