7-17
OTHER CONTROLS AND EQUIPMENT
69TB-01E
Heating and air conditioning system
Air outlet
52RM50220
(1) Windshield defroster outlet (2) Side defroster outlet
(3) Side outlet (4) Center outlet
(5) Floor outletCenter outlet (6) Rear floor outlet
(2)
(2)
(3)
(3)
(4)
(4)
(6)
(5)
(6)
(5)
(1)
(1)
Center outlet
69T070240
Move the knob (7) vertically or horizontally
to adjust the direction of airflow as desired.
CAUTION
Prolonged exposure to hot air from
the heater or air conditioner could
result in low temperature burns. All
vehicle occupants, particularly chil-
dren, the elderly, those with special
needs, individuals with delicate skin,
and sleeping individuals, should
maintain sufficient distance from the
air outlets to prevent prolonged
exposure to hot airflow.
To Next Page
