69TB-01E
For countries, in which the revised edition is applicable after the third edition of UN Regulation
No.10 has been enacted.
Installation of Radio Frequency (RF) Transmitting Equipment
Your vehicle is conformed to the revised edition since the third edition of UN Regulation No.10.
When you intend to use RF transmitting equipment in your vehicle, we strongly recommend that you select the equipment which
conforms to applicable rules or regulations in your country, and consult an authorized SUZUKI dealer or qualified service technician for
advice.
Table : Installing and the use of the on-board RF transmitter equipment
(1) Front
(2) Antenna installation position: Front left of roof
(3) Antenna installation position: Front right of roof
*The illustration is example of hatchback vehicle.
Frequency bands (MHz)
Antenna position at
vehicle*
Maximum output power (W)
144-146 Amateur band
84MM01201
50
430-440 Amateur band 50
1200-1300 Amateur band 10
(2)
(1)
(3)
