5-139
OPERATING YOUR VEHICLE
69TB-01E
Obstacle indication by parking sensor
69T050820
(1) Obstacle detected by rear center sen-
sors
(2) Obstacle detected by rear corner sen-
sors
(2) (1)
(2)
Upon detecting an obstacle, the parking sensor causes an interior buzzer to sound and a
symbol representing the obstacle appears on the information display and the parking sensor
indicator light blinks.
• A different symbol is displayed depending on the direction and distance of the obstacle.
• A buzzer located behind the rear seat sounds when a sensor at the rear detects an
obstacle.
• Warnings when obstacles are detected by rear sensors
Distance (approx.) Buzzer
Information
display
center
sensors
60 – 150 cm
(24 – 59 in)
Short beeps at long intervals
45 – 60 cm
(18 – 24 in)
Short beeps at short intervals
35 – 45 cm
(14 – 18 in)
Short beeps at very short intervals
Less than 35 cm
(14 in)
Continuous beep
