7-26
OTHER CONTROLS AND EQUIPMENT
69TB-01E
Blower speed selector (2)
69T070380
The blower speed selector (2) is used to
turn on the blower and to select blower
speed.
If “AUTO” switch (8) is pushed, the blower
speed will vary automatically as the cli-
mate control system maintains the
selected temperature.
Air intake selector (3)
55T070160
Push the air intake selector (3) to change
between the recirculated air and fresh air
mode.
If “AUTO” switch (8) is pushed, the air
intake will vary automatically as the climate
control system maintains the selected tem-
perature.
NOTE:
When you select the recirculated air mode
is selected, the automatic operation sys-
tem is deactivated even if you push
“AUTO” switch (8).
RECIRCULATED AIR (a)
When this mode is selected, inside air is
recirculated. This mode is suitable when
driving through dusty or polluted air such
as a tunnel, or when attempting to quickly
cool down or warm up the interior.
FRESH AIR (b)
When this mode is selected, outside air is
introduced. At the same time, the indicator
light (10) will turn off.
The fresh air position (b) and recirculated
air position (a) are selected alternately
each time the air intake selector is pushed.
NOTE:
If you select the recirculated air position (a)
for an extended period of time, the air in
the vehicle can become contaminated.
Therefore, you should occasionally select
the fresh air position (b).
(2)
(b)(a)
(3)
(10)
