8-6
VEHICLE LOADING AND TOWING
69TB-01E
Trailer hitch installation points
52RM60010
(1) Side
Maximum vertical load on trailer hitch
point (EU)
60 kg (132 lbs)
Maximum permissible overhang “a”
2WD model:
686 mm (27.0 in.)
4WD model:
684 mm (26.9 in.)
WARNING
(Continued)
When starting out after parking:
1) Depress the clutch and start the
engine.
2) Shift into gear, release the parking
brake, and slowly pull away from
the chocks.
3) Stop, apply the brakes firmly and
hold them.
4) Have another person remove the
chocks.
NOTICE
Because towing a trailer puts addi-
tional stress on your vehicle, more
frequent maintenance will be
required than under normal driving
conditions. Follow the schedule in
“Maintenance recommended under
severe driving conditions”.
To Next Page
