9-11
INSPECTION AND MAINTENANCE
69TB-01E
#3: Clutch fluid is supplied from brake fluid reservoir.
*2 Check or replace as necessary if you usually drive with high speed or high engine revolutions.
*3 Clean more frequently if the air flow from the air conditioner decreases.
Interval: This interval should be judged by
odometer reading or months, whichever
comes first.
km (x1000) 10 20 30 40 50 60
miles (x1000) 6.25 12.5 18.75 25 31.25 37.5
months6 1218243036
BRAKE
*5-1. Brake discs and pads (front) –I–I–I
Brake drums and shoes (rear) – – – I – –
*5-2. Brake hoses and pipes –––I––
5-3. Brake pedal – I – I – I
*5-4. Brake fluid (#3) –I–R–I
5-5. Parking brake lever and cable
Check, *Adjustment (1st 20000 km only)
– I – – – –
CHASSIS AND BODY
*6-1. Clutch pedal – I – I – I
*6-2. Clutch fluid (#3) –I–R–I
6-3. Tyres/Wheels – I – I – I
*6-4. Wheel bearings –I–I–I
*6-5. Drive axle boots – – – I – –
*6-6. Propeller shafts (4WD) –I–I–I
*6-7. Suspension system – – – I – –
*6-8. Steering system –––I––
*6-9.
Manual transmission oil Genuine “SUZUKI GEAR OIL 75W ”
– I – I – I
Other than “SUZUKI GEAR OIL 75W ”
– R – R – R
6-10. Continuously Variable Transmission (CVT) Fluid level – I – I – I
*Fluid deterioration check
*2
–I–I–I
Fluid change Replace every 70000 km (43750 miles)
*6-11. Transfer oil (4WD) – I – R – I
*6-12. Rear differential oil (4WD) –I–R–I
6-13. All latches, hinges and locks – – – I – –
*6-14. Air conditioner filter element
*3
–I–I–R
WARNING
The shock absorbers are filled with high pressure gas. Never attempt to disassemble them or throw them into a fire. Avoid
storing them near a heater or heating device. When scrapping the absorber, the gas must be released from the absorber
safely. Ask an authorized SUZUKI dealer or a qualified workshop for assistance.
