9-47
INSPECTION AND MAINTENANCE
69TB-01E
Side turn signal light
Outside rearview mirror type
LED is used. It is recommended that you
take your vehicle to an authorized SUZUKI
dealer for light replacement since special
procedures are required.
Fender type
64J195
Since the bulb is built-in type, replace it as
the light assembly. Remove the light
assembly by sliding the light housing left-
ward with your finger.
High mount stop light
LED is used. It is recommended that you
take your vehicle to an authorized SUZUKI
dealer or a qualified workshop for bulb
replacement since special procedures are
required.
Rear combination light
For LED tail / brake light, it is recom-
mended that you take your vehicle to an
authorized SUZUKI dealer or a qualified
workshop for light replacement since spe-
cial procedures are required.
69T090240
1) With the tailgate opened, remove the
bolts (1).
69T090410
2) Remove the light housing (2) by pull-
ing it straight back.
To Next Page
