10-19
EMERGENCY SERVICE
69TB-01E
System overview of added value services
• Data processing flow
65T50850
A: Server
B: Storage
C: Processing
D: DCM
D
A
B C
(1)
(2)
(3)
(4)
(6)(5)
(7)
(1) Customer activates service on Suzuki
Web site & accepts terms of services
according to GDPR.
(2) Server activates the service in the
DCM and defines which vehicle data
to collect.
(3) Defined vehicle data is collected by
the DCM.
(4) Data is shared with the server.
(5) Data is stored in the server.
(6) Data is processed in the server for ful-
filling the service.
(7) Processed data is presented to the
customer.
Visit the Suzuki Web site after launch of
the added value services for a list of eligi-
ble service.
