12-5
SPECIFICATIONS
69TB-01E
*1 Compression ratio vary depending on engine specification.
*2 Your vehicle is equipped with a lead-acid battery for exclusive use of the ENG A-STOP system. When replacing the lead-acid battery,
make sure to select the specified type for ENG A-STOP system. Consult an authorized SUZUKI dealer or a qualified workshop for
replacing the lead-acid battery.
*3 If the lithium-ion battery is completely discharged, the battery cannot be recharged. When replacing or disposing the lithium-ion bat-
tery, consult an authorized SUZUKI dealer or a qualified workshop.
ITEM: Engine
Type Z12E
Number of cylinders 3
Bore 74.0 mm (2.91 in.)
Stroke 92.8 mm (3.65 in.)
Piston displacement 1197 cm
3
(1197 cc, 73.0 cu.in)
Compression ratio 13.0 : 1 or 13.9 : 1
*1
ITEM: Electrical
Standard spark plug NGK ILKAR7Z11S
Lead-acid battery LN1 20HR 55Ah CCA 450A (EN)
*2
Lithium-ion battery Maintenance free
*3
Fuses See “INSPECTION AND MAINTENANCE” section.
