SV2000 WV205 - Page 13

1-5-3 E6161DC
3. How to Eject Manually
1. Turn the unit over.
2. Insert the shaft less than a diameter of 3 mm (e.g. screwdriver) straightly into the opening as shown.
3. Turn the shaft along with the opening clockwise.
4. Repeat steps 2 and 3 until the tray will open.
5. Pull the tray slowly manually.
[5] DVD Mechanism
(S-4)
(S-4)
(S-4)
Fig. D5
[6] AV CBA
(S-5)
(L-3)
(S-6)
(L-3)
Fig. D6
B
View for B
Turn the shaft along with
the opening clockwise.
Rear
Front
Opening
Shaft
(e.g. screwdriver)
