INSTALLATION OF THE OVEN DOOR
In order to re-place the oven door, perform the abovementioned steps
in reverse.
Figure 1.1 Figure 1.2 Figure 2.1 Figure 2.2
Completely
open the oven
door by pulling
it to yourself.
Afterwards,perform
the unlocking
process by pulling
the hinge lock
upwards with the
help of a screw
driver as shown in
gure 1.1.
Bring the hinge
lock to the widest
angle as shown
in gure 1.2.
Bring both hinges
connecting the
oven door to the
oven to the same
position.
Afterwards, close
the oven door as to
lean on the hinge
lock as shown in
gure 2.1.
To remove the
oven door, pull
it upwards by
holding it with
both hands when
close to the closed
position as shown
in gure 2.2.
Figure 1 Figure 2
