Svan SKI3600X - Cleaning and Maintenance of the Ovens Front Door Glass; Catalytic Walls; Rack Positions

44
CLEANING AND MAINTENANCE OF THE OVEN’S FRONT DOOR GLASS
Remove the prole by pressing the plastic latches on both left and
right sides as shown in gure 3 and pulling the prole towards yourself
as shown in gure 4. Then remove the inner-glass as shown in gure 5.
If required, middle glass can be removed in the same way. After cleaning
and maintenance are done, remount the glasses and the prole in reverse
order. Make sure the prole is properly seated in its place.
CATALYTIC WALLS *
Catalytic walls are located on the left and the right side of cavity under
the guides. Catalytic walls banish the bad smell and obtain the best
performance from the cooker. Catalytic walls also absorb oil residue and
clean your oven while it’s operating.
Removing the catalytic walls
In order to remove the catalytic walls; the guides must be pulled out.
As soon as the guides are pulled out, the catalytic walls will be released
automatically. The catalytic walls must be changed after 2-3 years.
RACK POSITIONS
It is important to place the wire grill into
the oven properly. Do not allow wire rack to
touch rear wall of the oven. Rack positions
are shown in the next gure. You may place
a deep tray or a standard tray in the lower
and upper wire racks.
Installing and removing wire racks
To remove wire racks, press the clips shown with arrows in the gure,
rst remove the lower, and than the upper side from installation location.
To install wire racks; reverse the procedure for removing wire rack.
Figure 3 Figure 4 Figure 5
1
2
Rack 4
Rack 3
Rack 2
Rack 1
