Sven MS-2020 - Page 4

ENG
4
2.1 Multimedia
Speaker System
Subwoofer control panels:
a LED display
b
/SOURCE: switch button of AUX/PC/Bluetooth/
FM/USB/SD (short press);
On/O button (long press)
c
: previous track (short press in the Player and
Bluetooth mode);
previous station* (short press in the Radio mode)
d Volume level control knob
e
/SCAN: Play/Pause (short press in the Player
mode);
Start/Stop auto scan (long press in the Radio mode)
f
: next track (short press in the Player and
Bluetooth mode);
next station* (short press in the Radio mode)
g ANTENNA: radio antenna input jack
h AUX/PC: jacks to connect PC, mobile devices,
andother audio sources
i OUTPUT: jack to connect satellites
j Power cord
k ON/OFF: power switch
l SD: slot for SD cards** containing МР3, WAV audio
les
m USB: port for a USB ash device** containing МР3,
WAV audio les
Fig. 2. Subwoofer rear panel
Fig. 1. Subwoofer control panel
Fig. 3. Side panel
l m
b
c
d
e
