2. PACKAGE CONTENTS
• Speaker system – 1 pc
• Mini-jack to mini-jack signal cable – 1 pc
• USB to micro USB power cable – 1 pc
• Operation Manual – 1 pc
• Warranty card – 1 pc
3. SAFETY PRECAUTIONS
• Do not open the multimedia speaker system (MSS) and do not perform repairs by yourself. Service
and repairs should be performed only by qualified specialists in an authorized service center. The
list of authorized service centers is available on www.sven.fi.
• Do not put foreign objects inside the holes of the MSS.
• Protect the MSS from high humidity, ingress of splashes and drops of water as well as dust on the
device; do not place any vessels with liquids on it.
• Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not expose
it to direct sunlight.
• Do not place open flame sources closely to MSS.
• Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.
4. TECHNICAL DESCRIPTION
PS-100BL Multimedia Speaker System (MSS) is designed to play music and sound games, movies,
etc. MSS can be connected to the audio source via a signal cable (included). Also the MSS has the
built-in V2.1 Bluetooth module, thanks to which it can be connected to audio sources without using
the cable, if they have built-in Bluetooth module.
Special features
• The MSS is compatible with PC, Media/МР3 players, mobile devices
• Built-in V2.1 + EDR Bluetooth module
• Ability to control the tracks (in Bluetooth mode)
• Headset mode
• AUX stereo input
• Passive emitters
• Built-in lithium battery with capacity 1150 mA•h
• Support for iPod
MSS design
a Operation mode indicator
b MIC: microphone
c Support for iPod
d Battery charging mode indicator
e DC 5V: micro USB port to connect
the device to a charger or USB port
of a notebook/PC
f AUX IN: jack to connect an external
sound source
Fig. 1. MSS design
ENG
2
Portable Speaker System
with Bluetooth
