ENGLISH SWAGTRON EB5 Pro Plus Electric Bike
Section 2. Assembling the Head
Step 1. Pull the head tube upright, and fold the latch up
and use the lock to close it. It will snap into place
(
1
).
Step 2. Open the head clamp on top of the head tube.
Step 3. Insert the stem into the head tube, pull it up
or down to adjust the height of the head to a
desired place.
Step 4. Close the head clamp to x the stem onto the
head tube (
2
).
Latch
Head Tube
Head Clamp
Stem
Lock
1
2
