ENGLISHSWAGTRON EB5 Pro Plus Electric Bike
Section 3. Folding, Unfolding & Adjusting Your EB5 Pro Plus eBike
Be careful not to position your ngers between the latch and the frame. Doing so may result in injury.
3.1 Unfolding the Head Tube & Frame
Step 1. Unfold the rear wheel / section and hold your eBike upright with the kickstand.
Step 2. Push the latch closed so that it's parallel with the bike's frame then turn the lock down towards the latch to
lock it in place (
3
).
Step 3. Pull the head tube and handlebars upright (
4
).
Step 4. Fold the latch up, then turn the lock so that its end is inserted into the latch to lock it in place (
5
).
Latch
Lock
Latch
Lock
3
4 5
