Swann DVR - Connecting to Your Monitor (Optional)

6
If you have a Monitor with a VGA connection, connect a VGA cable (not supplied) to the VGA output on the DVR then
connect the other end to the VGA input (1) on your Monitor.
Connect the DVR to your Monitor (optional) 5
8
A VGA cable and monitor
are not required when
using the HDMI cable.
1
1
2
3
4
5
6
7
8
ININININ
OUT
VIDEO IN HDMI
VGA
AUDIO LAN & USB
12V
