Swann DVR - Connecting the Power Adapter

9
Connect the supplied power adapter’s power connection (1) to the power input on the DVR first (this will minimise
sparking) then connect the power adapter to a spare wall socket.
All the connections have now been completed. You’re now ready to run through “The Setup Wizard” quick start guide
to configure the DVR.
Connect the Power Adapter 6
9
1
2
3
4
5
6
7
8
ININININ
OUT
VIDEO IN HDMI
VGA
AUDIO LAN & USB
12V
1
