PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
FIRE DAMPER - FD
50
ACTUATORS
ELECTRIC
ACTUATOR
Position of thermal
fuse
BB
HH
H < 300
Thermal fuse is located on the underside
of the fire damper.
300 ≤ H ≤ 450
Thermal fuse is located on the same side
as Belimo actuator (above).
H > 450
Thermal fuse is located on the same side
as Belimo actuator (below).
Bottom view Side view Side view
