FIRE DAMPER - FD
PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
MODELS
Casings
Actuators
R (R-S)
Manual operating mechanism, optionally with end switches (R-S). In case
of fire, the fire damper closes automatically. Damper closing can be initiated
either by thermal fuse melting, or by manual activation on the operating
mechanism. Upon closur
e, damper blade is locked in closed position and
can only be opened manually. Thermal fuse melting point is 72 °C.
M230-S
Belimo 230 V electro motor operating mechanism, comes with
integrated end switches. In case of fire, the fire damper closes
automatically. Damper closing can be initiated either by thermoelectric
release device or remotely by triggering the electro motor. Upon
closure, damper blade is locked in closed position and can be opened by
sending a signal to electro motor. Standard thermoelectric release point is
72 °C, optional 95 °C.
M24-S
Belimo 24 V electro motor operating mechanism, comes with integrated
end switches. In case of fire, the
fire damper closes automatically.
Damper closing can be initiated either by thermoelectric release device
or remotely by triggering the electro motor. Upon closure, damper blade
is locked in closed position and can be opened by sending a signal to
electro motor. Standard thermoelectric release point is 72 °C,
optional 95 °C.
EX
ATEX rated fire dampers are equipped with Schischek ExMax-5.10-
BF actuators, ExPro-TT thermal switches and ExBox-BF plenum boxes.
Optional casing can be produced in AISI316L stainless steel.
Ordering key
FD25
Fire damper with 25 mm damper blade and fire
classification up to EI120S.
Sizes range from 100x200 till 800x600.
FD40
Fire damper with 40 mm damper blade and fire
classification up to EI120S.
Sizes range from 800x600 till 1500x800.
FD25 - APP
Fire damper with integrated Applique installation kit
with 25 mm damper blade and fire classification up to
EI90S. Sizes range from 100x200 till 800x600.
FD25 - MF1
Fire damper with integrated MF1 installation frame
with 25 mm damper blade.
Sizes range from 100x200 till 800x600.
FD25/FD40 - MF2
Fire damper with integrated MF2 installation frame
with and fire classification up to EI90S. Sizes range
from 100x200 till 1500x800.
(1) Damper type (2) Dimension (3) Mechanism type (4) Mounted accessories
FD25 - 400x300 - M230-S
- IH
(1)
(2)
FD25 100x200 till 800x600
FD40 800x600 till 1500x800
FD25-APP 100x200 till 800x600
FD25-MF1 100x200 till 800x600
FD25-MF2 100x200 till 800x600
FD40-MF2 800x600 till 1500x800
Damper dimensions
B(W) x H [mm]
(3)
(4)
R
R-S
M230-S
M24-S
EX
IH
- manual drive
- manual drive with limit switches
- electric actuator AC230 V
- electric actuator AC/DC 24 V
-
- electric actuator Schischek ExMax-5.10-BF
+ExPro-TT+ExBox-BF
- inspection hatch
