FB 430 / FB 450 / FB 500 / FB 510
Dok: 101498D-GB 2103
USE
SWEPAC FB430 / FB 450 / FB500 / FB 510
are used to pack ballast under foundations, in connection with road
building, in trenches, etc. On account of the forward/reverse fun-
ction, the machine is very suitable for packing in tight spaces and as
a complement to larger packing equipment. The innitely variable
speed control makes it possible to move with great precision and to
pack without moving.
CONTENTS
USE ............................................................................
SAFETY INSTRUCTIONS .......................................
STANDARDS ........................................................... .
SIGNS ........................................................................
TECNICAL DATA ..................................................... .
METHOD OF OPERATION .....................................
TECHNICAL DESCRIPTION ...................................
DAILY CHECKS ....................................................... .
BEFORE STARTING .................................................
STARTING, Yanmar ..................................................
STOPPING ................................................................
BEFORE STARTING..................................................
STARTING, Hatz........................................................
STOPPING...................................................................
OPERATING INSTRUCTIONS .................................
TRANSPORTATION ............................................... ..
BELT TENSION / REPLACEMENT OF
THE BELT....................................................................
MEASURING AND ADJUSTMENT THE
HYDRAULIC PRESSURE FB 450 / FB 510..............
HYDRAULIC DIAGRAMM 450 / FB 510.................
MEASURING AND ADJUSTMENT THE
HYDRAULIC PRESSURE FB 430 / FB 500..............
HYDRAULIC DIAGRAMM 430 / FB 500.................
COMPACTION INDICATOR (SCI)...........................
EC-DECLARATION OF CONFORMITY...................
