41
2) Oiling the Arm
Use the oiling device to oil each part of the arm. Do not overfill the tank.
Oil hole
• upper shaft bushing • presser foot drive lever shaft
• needle bar crank rod • needle bar lever
• needle bar and controller • presser foot shaft
• take-up lever drive lever shaft
