Fitted Equipment
106
THE OMNIVENT (12V) ROOFLIGHT
The Omnivent is a double glazed rooflight
constructed from a synthetic ultra-violet
screened material. Its side operating
mechanism allows a completely free central
opening with built-in fixed ventilation when
closed.
Red Switch = Mode of Operation
Induction (IN)
Expel (OUT)
Black Switch = Speed Control
1, 2 and 3
Omnivents give no fixed ventilation when set
on induction.
IN
OFF
OUT
THE BLIZZARD 1500 AIR CONDITIONER
To set the required temperature adjust the
RED/BLUE selector control knob against the
indicator mark on the outer bezel. Airflow
direction can be achieved fore and aft by
adjustment of the air outlet louvres.
Attention
Never obstruct the air inlets and outlets
The air conditioning compressor runs during
the refrigerating phase, if switched on and off
at once it may get damaged. Therefore, it is
very important to wait at least 3 minutes
before attempting to switch it on again.
Main
Switch
Position air conditioner ON
Position air conditioner OFF
Position fresh air
Position warm air
ON-OFF
Warm/Cold
Dual Switch
Starting and function selection
Warm-Cold
Fan
Switch
Position high speed
Position low speed
Air Speed
Thermostat
By rotating the knob clockwise, temperature
increases (max 40°C)
By rotating the knob anti-clockwise,
temperature reduces (min 18°C)
Air Temperature
(18°C-40°C)
