Swift 2004 User Manual

Fitted Equipment
105
Always pull the doorscreen close to the
centre. It is not advisable to pull close to the
top or bottom as this will cause snagging
and uneven running.
Caution
When opening or releasing the
doorscreen, care must be taken to avoid
trapping fingers.
Do not allow the doorscreen to slam
open.
SEITZ ENTRANCE DOOR
To open from the outside, pull the opening
lever in the door handle.
To open from the inside, pull the opening
lever in the recessed handle.
To lock the door from the outside turn the
key to the left, to unlock turn the key to the
right.
To lock the door from the inside, depress the
locking button. To unlock pull the handle.
The window is opened by depressing the
button on the catches and turning through
90°, open the pane fully until it locates. To
close pull the pane back and close the
catches.
The door flynet and blind operate
independently by sliding together and
engaging.
ROOF LIGHTS
When opening the roof lights, care must be
taken to release the locking mechanism as
the unit is raised.
Roof lights must be fully closed when
towing.
Roof lights provide 12,500mm
2
of fixed
ventilation each.
WINDOWS
To open press the knobs in the middle of the
catches and turn through 90°. Swivel the
pane open as required.
To close the window, open the window as far
as possible and slowly close again, turn the
catches through 90° to close.
All opening windows have two catch
positions. The first position is for ventilation
the second seals the window from ventilation
and rain.
HEKI-2 ROOF LIGHT (SEITZ)
The lift/tilt roof light can be set in 3 positions
by means of pneumatic springs.
Position 1 lifts the pane 12mm without
allowing rain to enter the caravan.
Position 2 sets the pane to a 150mm
opening and locks with a bar.
Position 3 opens the pane through 55°.
A fully adjustable flyscreen and black-out
screen are built into the inner frame. The
flyscreen can be drawn independently and
the black-out screen is variable for partial or
full black-out.
Forced ventilation functions via a brush lined
duct instead of a ventilated pane.
A cover hood can be fitted for winter
protection.
Heki-2 roof lights provide 13,200mm
2
of fixed
ventilation
MINI HEKI ROOFLIGHT
To open depress button and push bar
upwards. The rooflight has two open
ventilation positions and a fully open
position.
The blind and flynet operate independently
of each other and are engaged by
connecting to each other and sliding.
