Swift 2004 User Manual

Fitted Equipment
66
3. Switch the LPG switch to position (F).
4. Switch the heating cartridge switch to
position (A).
HEATING AND WARM WATER WITH 230 V
HEATING CARTRIDGE
1. Switch the circulation pump switch to
position (I).
2. Switch the LPG switch to position (E).
3. Switch the heating cartridge switch to the
desired output position (B, C or D).
In the illustration, an output of 2100 W
has been selected.
4. Adjust the temperature to the desired
level (5-30°C) using the TPS control
thermostat (K).
HEATING AND WARM WATER WITH LPG
BOILER
1. Open the LPG shut-off valve.
2. Switch the circulation pump switch to
position (I).
3. Switch the LPG switch to position (F).
4. Switch the heating cartridge switch to
position (A).
5. Adjust the temperature to the desired
level (5-30°C) using the TPS control
thermostat (K).
HEATING AND WARM WATER WITH BOTH
230 V HEATING CARTRIDGE AND LPG
BOILER
(Use only when electricity or gas alone is not
sufficient)
1. Open the LPG shut-off valve.
2. Switch the circulation pump switch to
position (I).
3. Switch the LPG switch to position (F).
4. Switch the heating cartridge switch to the
desired output position (B, C or D).
In the illustration, an output of 2100 W
has been selected.
5. Adjust the temperature to the desired
level (5-30°C) using the TPS control
thermostat (K).
SETTINGS FOR OPERATION OF THE
HEATING SYSTEM AND WARM WATER
HEATER
For more information on the settings on the
panel, please refer to the 'Control Panel'
section.
SWITCHING OFF THE LPG BOILER,
HEATING CARTRIDGE AND CIRCULATION
PUMP
1. Switch all three switches on the control
panel to the O-position (H, E, A).
2. Close the main switch to the heating
system if the vehicle will not be used.
If the main switch is not closed, the boiler
will remain in the stand-by position and
use a small amount of electricity.
3. Close the LPG shut-off valve.
IF THE RED LED-LIGHT COMES ON
The boiler is fitted with an ionised flame
sensor. This means that if the flame goes out
for some reason, the electronics will attempt
to re-light it. If the flame is not re-lit within
ten seconds, the solenoid valve switches off
the gas supply, the electronics are blocked
and the red LED (G) on the control panel is
switched on. The electronics must be reset
before the boiler can be started.
Resetting from the blocked position:
1. Switch the LPG switch to position (E).
The LED (G) will go out.
2. Wait approx. 30 seconds while the
electronics reset the block.
3. Switch the LPG switch to position (F).
The electronics will once again attempt to
start the boiler.
