Fitted Equipment
4. Clip the cover
back in place.
Note: For 12V
DC : 1 light bulb
12V, 2W
Please contact Dometic Service Centres for
replacement light bulbs.
CHANGING THE DECOR PANEL
1. Open the door and loosen the hinge
screw.
2. Take off the door by moving it upwards.
3. Unscrew the door strip (3 screws).
4. Remove the decor plate and insert a new
decor plate.
5. Screw the door strip back in position.
6. Put the door back on.
7. Tighten the hinge screw.
Dimensions of the panels in mm:
Model Height Width Thickness
RM 7271 /..75 713+/-1 453.5+/-1 3.2
RM 7361 /..65 713+/-1 453.5+/-1 3.2
RM 7291 /..95 718+/-1 491.5+/-1 3.2
RM 7401 /..05 718+/-1 491.5+/-1 3.2
Changing the doorhang
It is not always possible to change the door
when the refrigerator is installed.
1. Open the door, unscrew the hinge
screw and keep it to hand.
2. Take off the door by moving it upwards.
5. Attach the door.
8. Screw the hinge screw back in
76
4
1
2
3
4
5
7
6
