Fitted Equipment
97
C-200 CW only C-200 CWE only
C-200 CW
only
THETFORD CASSETTE
C-200 CW (Manual)
and C-200 CWE (Electric)
FEATURES
1. Removable seat and cover.
2. Rotatable bowl.
3. Valve blade handle: opens and closes
valve blade.
4. Flush-handle activates the flush by lifting
and pushing down the handle.
4a C-200 CWE. Flush button: activates
flush.
4b C-200 CWE. Valve blade buttons: open
and close valve blade electronically.
5. Power-supply for the waste-level
indicator: two batteries, type: Penlite 1,5V
AA alkaline.
6. Waste-level indicator: indicates when
holding tank requires emptying.
7. Rotating pour-out spout: makes emptying
holding tank easy and convenient.
8. Upper carrying handle
9. Automatic holding tank vent: vents the
holding tank when the tank is inserted in
the toilet. This prevents under- or
overpressure in the holding tank.
10. Valve blade opener.
11. Sliding cover: closes automatically when
holding tank is taken out. Guarantees
optimal hygiene.
12. Valve-blade
13. Vent button: vents the holding tank to
avoid splashing while emptying.
14. Hand grip
15. Access door
16. Waterfill door
05
04
06
04a 06 16
04b
03
01
02
08 07 09 14 12
13
11
14
10
15
