Swisher RTB12544A - Front Skirt Detail; Hitch Detail

When ordering replacement parts
* = USE PAINT CODE: TC=TEX.RED,S=SILVER,TK=TEX.BLACK
Item # Description Part #
1 Bolt - Serr Flange, 1/4-20 X 3/4 GR5 ZY NB690
2 Washer - Fender, 1/4X1 1/4OD Gr 2 ZY 11520
3 Rubber Flapper 10384
4 Nut - Serr Flange, 1/4-20 Grade 5 ZY NB524
FRONT SKIRT ASSEMBLY
FIGURE 1
11
1
3
4
2
