RIGHT-HAND SIDE VIEW OF
SILVER VASE / GRAN TURISMO
1) Fuel tank cap
2) Fuel tank
3) Instrument panel
4) Headlight
5) Taillight
6) Horn
7) Front turning indicator
8) Rear turning indicator
9) Rear brake disc
10) Rear brake calliper
11) Rear brake pedal
12) Rear brake pump
13) Engine oil lter
14) Air lter
15) Engine oil dipstick
16) Rear shock absorber spring preload adjustment
ring nut
17) Hydraulic fork adjuster
18) Passenger handle
19) Exhaust silencers
20) Throttle body
