SPEEDOMETER
1) Trip reset/scale change button (km or mi)
2) Speedometer
3) Display
The instrument consists of a speedometer (2) with
two scales (km/h or mph) and a display (3) showing
the total km or mi done (not resettable) at the top
(3a) and the trip km or mi from the last reset at the
bottom (3b).
To reset the trip counter, press the button (1); to
change the scale from km to mi or vice versa, press
and hold down the button (1).
.
REVOLUTION COUNTER
This instrument allows you to control the number
of engine revolutions and not go over the limit indi-
cated in the red area (1).
Keep the engine speed within the black scale (2) and
do not go over 10000 rpm.
CAUTION*: If you exceed 10000 rpm (red area 1),
the engine may be damaged.
