SPELLBINDER BLUE™
(This is the model name for warranty claims)
*Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY section above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded + ** Both a unique Fender® part and a Safety Requirement part as defined above.
12
PARTS LIST:
CABINET ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0070639000 HANDLE RUBBER CONTOUR @ TOP
8 0021972000 NUT T 10-32x3/4 STR 3 PRNG BLX
@ SPEAKERS & TOP HANDLE
AR
0064107000
CARPET BLUE TWEED
1 0070629000 CORNER PLASTIC 100DEG LEFT SIDE
1 0070630000 CORNER PLASTIC 100DEG RIGHT SIDE
4 0070452000 CORNER PLASTIC CHEVRON BEVEL EDGE
24 0016627000 SCRW SMA 8x3/4 OHP BLX @ PLASTIC CORNERS
4 0048471000 SCRW M 10-32x1 OHP STL BLX @ TOP HANDLE
4
0033380000 SCRW SMAB 8x1 THP BLX
@ FEET
12 0026576000
SCRW SMA 8x5/8 THP BLK SELL 049
@ TILT-BACK FOOT
6 0017439000
SCRW SMA 6x1/2 PHP BLX
@ VENT
1 0067259000
VENT BABY BABY BLUE
4 0048976000
FOOT RUBBER 1-1/2" BXR 115
@ BOTTOM
1 0070640000
FOOT CABINET TILT-BACK
@ BOTTOM
PARTS LIST:
END ITEM ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1
0076011000
*CABINET ASSY SPELLBINDER BLUE
1
0076027000
*GRILLE CHROME SPELLBINDER BLUE
1
0076017000
SPKR 10" 4 OHM EMINENCE NEO
1 0067254000 TWEETER NEW CAL. BLONDE
1
0076028000
*PLATE ASSY XOVER SPELLBINDER BLUE
4 0065940000
BLACK STOPPER GRILLE MOUNT GRILLE MOUNT
4 0067025000 SMS #8X1-1/2 PH TRUSS S/STEEL GRILLE MOUNT
4
0054264000
SCRW SMAB 8x3-4 THP BLX HORN MOUNT
4
0026577000
SCRW M 10-32x1 PHP BLX 10” SPEAKER MOUNT
4 0036199000 SCRW M 8-32x1-3/16 OHP BLX CP sell 049 CHASSIS MOUNT
4
0029527000
WSHR FNSH 8-5/8 FLNGD BLX WX CHASSIS MOUNT
4
0026576000
SCRW SMA 8x5/8 THP BLK XOVER PLATE MOUNT
0053997000
** CORD PWR W/IEC CONN 100V
1
0047248000
** CORD PWR W/IEC CONN DOM
0047249000
** CORD PWR W/IEC CONN 230V UK
0047250000
** CORD PWR W/IEC CONN 250V
0047251000
** CORD PWR W/IEC CONN 230V
PARTS LIST:
XOVER PLATE ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1
0076013000
PLATE XOVER SPELLBINDER BLUE
1 0066495000 LPAD 8 OHM 50W #AT-50H - L-8 OHM
