SPELLBINDER BLUE™
(This is the model name for warranty claims)
*Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY section above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded + ** Both a unique Fender® part and a Safety Requirement part as defined above.
13
PARTS LIST:
XOVER PLATE ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0064463000 KNOB PLASTIC W/POINTER, XOVER
4 0073612000 STNDOFF HX M/F AL 6-32x1-1/4
1
0029894000
WSHR LCK INTL 3/8x .500x .022 NI @ LPAD
1
0016352000
NUT HEX 3/8-32x3/32 TK NI( sell 049) @ LPAD
4 0031184000 SCRW M 6-32x1/4 PHP BLX ITLW @ STANDOFFS
To Next Page
